Prisma-E Panelboard
Description:
Schneider Electric has developed a modular, module-based, multi-purpose low-voltage distribution cabinet that incorporates standardized application concepts. Featuring industry-leading technical specifications and product performance, it meets customers diverse application requirements across various scenarios.
Presentation
Documents
Structural Characteristics
|
Size(mm) |
500/700/900/1100/1300/1650/1850 |
|
Rated short-time withstand current |
20KA 1s |
|
Rated operating voltage(Ue) |
690V(AC) |
|
Rated insulation voltage(Ui) |
1000V(AC) |
|
Rated peak withstand current |
42 KA |
|
Protection Level |
IP30/40/54 |
Benefits
People safety
Thermal monitoring/Internal arc containment and arc flash protection
Power availability
Up to IP 54 protection degree for dusty and damp environments to ensure your continuous operation
Sustainability
Green Premium product — non-hazardous material, designed for optimized recycling, and reduced carbon footprint and energy consumption.
Application
Schneider Prisma-E series LV power distribution box and control box (cabinet) is a new generation of standardized distribution system carefully designed by Schneider for users. Based on decades of professional design experience, its quality is trustworthy. It has active safety and passive safety design, and its professional quality control ensures the quality of end products. It is widely used in public and commercial buildings, industry, infrastructure and many other fields.
Schneider Prisma-E series LV power distribution box and control box (cabinet) is a new generation of standardized distribution system carefully designed by Schneider for users. Based on decades of professional design experience, its quality is trustworthy. It has active safety and passive safety design, and its professional quality control ensures the quality of end products. It is widely used in public and commercial buildings, industry, infrastructure and many other fields.
Applications
Commercial Real Estate
Data Center
Transportation
